TPS71401DRVR IC Electronic Components Quiescent Current LOW-DROPOUT LINEAR REGULATOR

AYE TECHNOLOGY CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap TPS71401DRVR IC Electronic Components Quiescent Current LOW-DROPOUT LINEAR REGULATOR from wholesalers

    Buy cheap TPS71401DRVR IC Electronic Components Quiescent Current LOW-DROPOUT LINEAR REGULATOR from wholesalers
    • Buy cheap TPS71401DRVR IC Electronic Components Quiescent Current LOW-DROPOUT LINEAR REGULATOR from wholesalers
    • Buy cheap TPS71401DRVR IC Electronic Components Quiescent Current LOW-DROPOUT LINEAR REGULATOR from wholesalers

    TPS71401DRVR IC Electronic Components Quiescent Current LOW-DROPOUT LINEAR REGULATOR

    Ask Lasest Price
    Brand Name : TI
    Model Number : TPS71401DRVR
    Price : Consultant
    Payment Terms : T/T
    Supply Ability : 4100pcs/day
    Delivery Time : In Stock
    • Product Details
    • Company Profile

    TPS71401DRVR IC Electronic Components Quiescent Current LOW-DROPOUT LINEAR REGULATOR

    TPS71401DRVR IC Electronic Components Quiescent Current LOW-DROPOUT LINEAR REGULATOR
    Product description

    Part number TPS71401DRVR is manufactured by TI Company and distributed by AYE. As one of the leading distributors of electronic products, we carry many electronic components from the world's top manufacturers.

    For more information on TPS71401DRVR detailed specifications, quotations, lead times, payment terms and more, please do not hesitate to contact us. In order to process your enquiry, please add the quantity to your message.


    Product details/Parameters

    Number of output interfaces1
    Output voltage1.2 V ~ 8.8 V
    Dissipated power1.54 W
    Quiescent current3.00 µA
    Output Capacitor TypeCeramic
    Sag voltage0.67 V @ 80mA
    Adjust output number1
    Output Current (Max)1.1 A
    Operating Temperature (Max)125 ℃
    Operating temperature (Min)40 ℃
    Accuracy4%
    Input voltage2.5V ~ 10V

    Part of the recommended inventory list
    TPS71433DCKRTISC-70-5
    TPS71433DCKTTISC-70-5
    TPS71401DCKRTISC-70-5
    TPS7148QDTISOIC-8
    TPS71401DCKTTISC-70-5
    TPS71401DRVTTIWDFN-6
    TPS71401DRVRTIWDFN-6
    TPS71433DRVTTIWDFN-6
    TPS7148QPTIPDIP-8
    TPS71433DRVRTIWDFN-6

    The TPS714xx low-dropout (LDO) voltage regulators offer the benefits of wide input voltage range, low-dropout voltage, low-power operation, and miniaturized packaging. These devices, which operate over an input range of 2.5V to 10V, are stable with any capacitor ≥ 0.47µF. The 2.5V to 10V input voltage range, combined with 3.2µA quiescent current, makes this device particularly well-suited for two-cell alkaline, and two-cell lithium, and other low quiescent current sensitive battery applications. The low dropout voltage and low quiescent current allow operation at extremely low power levels. Therefore, the devices are ideal for power battery management ICs. Specifically, because the device is enabled as soon as the applied voltage reaches the minimum input voltage, the output is quickly available to power continuously-operating, battery-charging ICs.

    The typical PNP pass transistor has been replaced by a PMOS pass element. Because the PMOS pass element behaves as a low-value resistor, the low dropout voltage (typically 415mV at 50mA of load current) is directly proportional to the load current. The quiescent current (3.2µA, typical) is stable over the entire range of the output load current (0mA to 80mA).

    The TPS714xx is available in a 2mm × 2mm SON-6 package ideal for high power dissipation, or an SC70-5 package ideal for handheld and ultra-portable applications.



    advantages


    1. Parts source determine price, The source of our parts is very initial.

    2. Price can be negotiable based on quantity; delivery terms;

    3. We will try to help customers to reduce freight charge.

    4. The price of products changes frequently, if you need to quote price, please inform the model which you need,we will give you the reasonable price as the standard quoted price in the same day


    FAQ

    Q1: What company do we belong to?
    A1: We are a trader and agent.
    Q2: How long is our delivery time?
    A2: This depends on the quantity of the goods you ordered, we have stock, usually 15-20 days delivery time.
    Q3: How to order?
    A3: Please mail your order or request to us, and tell us the following information: shipping details, including company name, address, person, phone number, quantity.
    Q4: How many discounts are available for ordering products?
    A4: As long as you provide us with your demand, we will give you the best price.
